Agilent / HP / Keysight 34959A

34959A Breadboard Module for 34980A

Description

This is a Breadboard Module for the 34980A Multifunction Switch/Measure Unit can be used to create custom designs inside the Mainframe.

You can control your circuits with access to both the +12V and +5V supplies, 16 GPIO ports, and 32 relay drive lines.

The faceplate has cutouts for the most common connectors.

The breadboard module can be programmed using standard read and write commands in SCPI.

Key Points

+12V and +5V power supplies

32 drive lines

16 GPIO ports

5.4" x 7.5" x .9" space for custom circuitry

Programmable with SCPI commands

Specifications

Power supply: +12V and +5V

Drive lines: 32

GPIO ports: 16
