Fluke PM3082
Analog Oscilloscope DC to > 100 MHz
Description
This Analog Oscilloscope featuring two channels with full attenuators, sensitivities to 2mV/div and two channels with 0.1 and 0.5V/div sensitivity, 1% voltage and timing accuracy, auto cal function, Auto set for automatic setup of an optimized display of input signals. This unit's on screen displays include ground and trigger level indicators, Powerful cursor measurements with direct numerical readout, delayed timebase, wide rage of trigger possibilities including HDTV, RS-232 interface for full remote control (CPL protocol).
Key Points
Bandwidth 100MHz
Rise time 3.5ns
Min. Vertical Sensitivity 2mV/div
Maximum Vertical Sensitivity 5V/div
Input Coupling AC,DC
Specifications
Input Channels:Two fully attenuated channels, plus two limited attenuated channels
Frequency Response: DC to > 100 MHz
Bandwidth Limiter: 20 MHz -3 db
Rise Time: < 3.50 ns
Input Impedance: 1 ohm ±1
