Agilent / HP / Keysight N5409A

N5409A Fully Buffered DIMM Compliance Application for Infiniium Oscilloscopes

Please help us customize your browsing experience, by selecting one the below.

Description

The Agilent N5409A is a Fully Buffered DIMM Compliance Application tool. This will provide you with a fast and easy way to characterize and evaluate the signal integrity of your high speed FB-DIMM signals and your reference clock. The tests performed by the N5409A are based on the JEDEC High Speed Point-to-Point Link Specification.

Key Points

Automation:
Test setup wizard guides you through test selection, configuration, connection, execution, and results reporting
Measurement connection setups are displayed
Oscilloscope setup is automatically configured for each test
Test results report documents test configuration, measurements made, pass/fail status, margin analysis, and waveforms
Standards Supported:
FB-DIMM 1.0
Supports both JEDEC and Intel Eye Masks
Built-in AMB control for test setup (DIMM and AMB testing)
