Agilent / HP / Keysight N2272A
N2272A 1 GHz 1x9 RF Multiplexer Module
Description
This RF high density module provides a 1x9 multiplexer which can be widely used in RF test and measurement systems. It consists of a series of eight RF latching relays in a tree structure.
This unit's low insertion loss, high isolation, and excellent VSWR performance guarantee the RF signals will not be degraded when routed from source to destination.
In order to decrease the degradation when cascading, the auxiliary channel (channel 08) with smaller insertion loss and lower VSWR, is provided to extend the channel count.
This is done by connecting it to the COM channel of the next N2272A module.
Key Points
Ease of channel density extension
Ease of wiring with BNC connectors
Ideal for high density RF signal routing
Specifications
Insertion Loss: <0.5dB
Cross talk: <-75dB
SWR: <1.20
Bandwidth: 1GHz
Impedance: 50Ω
Number of channels: 9Ch
Maximum Voltage: 24V
Maximum Current: 1A
