Agilent / HP / Keysight N2268A
N2268A Dual 1x4 RF Multiplexer Module (3.0 GHz)
Description
This multiplexer module has two 1x4 independent multiplexers with SMA connectors, delivering high performance, very low insertion loss, high isolation, and excellent VSWR performance.
This high density RF multiplexer module is an economical RF signal switching solution.
Its 3.5GHz bandwidth guarantees signals will not be degraded when switched from source to destination.
Each group of four channels is isolated from the other and from the chassis to prevent ground loops.
The wide bandwidth performance enables quality dynamic range RF signal measurements using oscilloscopes, spectrum analyzers, network analyzers, and GSM/CDMA test sets.
Typical test applications include switching signals of Bluetooth transceivers and L1/L2GPS receivers, 1.8/1.9GHz wireless communication devices CDMA, 3G, and mobile phones.
It can be also used to route satellite signals.
Key Points
Ideal for wireless communication test
Insertion loss <1.7dB at 3.5GHz
Spectrum analyzers
Network analyzers
GSM/CDMA test sets
Specifications
AC Volts Range Min/Max: 30V
DC Volts Range Min/Max: 30V
Characteristic Impedance: 50 Ω
Maximum Scan Rate: 20 Chans./sec
Maximum Voltage: 30V, DC + AC peak
Maximum Current: 0.5A, DC + AC peak
Maximum Power: (per channel) 10W
