Agilent / HP / Keysight N2260A

N2260A 2-Wire, 40-Channel Multiplexer Module

Please help us customize your browsing experience, by selecting one the below.

Description

This unit is high density re configurable multiplexer (MUX) module for general production test.

It can be operated in either SCPI or 3488A mode.

A connection terminal is not provided with the N2260A module.

Screw terminal block, crimp and insert terminal block, and DIN96 to D50/25 cables are available separately for ease of wiring.

Key Points

One 80 channel, 1 wire MUX

One 40 channel , 2 wire MUX

Dual independent 20 channel, 2 wire MUXs

One 20 channel, 4 wire MUX

1A, 200V

Plus 2 non latching relays (Mux)

Configurable for 1, 2, and 4 wire modes

Specifications

AC Volts Range Min/Max: 200V

DC Volts Range Min/Max: 200V

Max Channels: 80
