Agilent / HP / Keysight E3612A
E3612A 30W Power Supply, 60V, 0.5A or 120V, 0.25A
Description
The E3600 Series of low-cost benchtop power supplies give you the performance of system power supplies at a decent price. All E3600 family members provide clean power with excellent regulation and a fast transient response. The E3600 Series single output non-programmable models are described on this page. Refer to page 3 for information on dual-output and triple-output non programmable models.
E3612A designed for general laboratory use. The constant-voltage, constant-current output allows operation as either a voltage or current source. The changeover occurs automatically, based on the load. This model has two ranges, allowing more current at a lower voltage. For higher output voltages, supplies can be connected in series. This model also has overload protection. A continuously acting constant current circuit protects the power supply against all overloads including a direct short placed across the terminals in a constant voltage operation.
Key Points
30W Single output, Dual range
Constant voltage (CV) and Constant current (CC) modes
Digital voltage and current meters
Low noise and excellent regulation
10 turn voltage and current adjust potentiometers
Specifications
Number of outputs:1
Number of Output Ranges:2
Power (max): 30 W
DC Output Rating:
60 V, 0.5 A
120 V, 0.25 A
Meter Resolution:
Voltage:100 mV
Current: 1 mA
Voltage rms: 200 µV
Peak-to-Peak: 2 mV
