Agilent / HP / Keysight 81655A

81655A Single Fabry-Perot Laser Source, 1310 nm, >13 dBm (20 mW)

Please help us customize your browsing experience, by selecting one the below.

Description

This single wavelength module is to be used in conjunction with optical power meter modules for insertion loss, optical return loss and PDL measurement of broadband components and fiber.

This Module is insensitive to back reflections and is stabilized for short and long term applications.

Key Points

1310nm

20mW (>13dBm) output power

CW power stability: ±0.03db (24h)

Internal digital modulation

Specifications

Form Factor: Module (proprietary interface/bus)

Type: Laser

Minimum Wavelength: 1310nm

Maximum Wavelength: 1310nm

Maximum Power: 20mW

Fiber Type: Singlemode (9/125um)

Beam Waist Diameter: 9um
