Agilent / HP / Keysight 66321B
66321B Mobile Comm DC Source with Battery Emulation
Description
This Mobile Communications DC Source provides fast transient response, exceptional sourcing, output resistance programming, and precision measurement.
This product is specially designed for testing next generation digital wireless communications products.
This unit offers a new capability that simulates the internal resistance of a battery or battery pack.
Additionally, these high performance models offer improved transient response and stable output operation with either short or long load leads.
The unit provides 0 to 15V @ 3A.
Key Points
Programmable output response compensation
Stable output for either long or short load leads
Voltmeter measures external voltage
<
p>Fast transient response as low as <20µs
Specifications
Number of Outputs: 1o/p
Voltage Load Regulation: 5mV
Voltage Line Regulation: 0.5mV
