Agilent / HP / Keysight E8358A

This Analyzer is an instrument which measures the complex transmission and reflection characteristics of two port devices in the frequency domain.

It does this by sampling the incident signal, separating the transmitted and reflected waves, and then performing ratios that are directly related to the reflection and transmission coefficients of the two-port.

Frequency is swept to rapidly obtain amplitude and phase information over a band of frequencies of interest.

This unit is utilize synthesized frequency sources to provide a known test stimulus that can sweep across a range of frequencies or power levels.
