Agilent / HP 4270A
Automatic Capacitance Bridge
Description
This Automatic Capacitance Bridge automatically measures capacitance, equivalent parallel conductance, and dissipation factor.
It offers 5 digit readout of capacitance from full scale ranges of 18.000pF to 1.2000µF with 0.001pF resolution and measurement speed of 0.5seconds.
Key Points
Conductance ranges from 899.9 nmhos to 8.999 mmhos
Four measurement frequencies from 1KHz to 1MHz
Basic accuracies of (±n% of reading + number of digits): capacitance (0.2-0.5 + 1), conductance (1-3 + 10), dissipation [1-3 + (10 + internal capacitor/capacitance measured)]
Specifications
Conductance ranges: 899.9nmhos to 8.999 mmhos
Capacitance range: 18.000pF to 1.2000µF
Measurement speed: 0.5seconds
Measurement frequencies: 1KHz to 1MHz
